Methods and Systems for Integrating Fluid Dispensing Technology with Stereolithography (Divisional)

Methods and Systems for Integrating Fluid Dispensing Technology with Stereolithography (Divisional)
Inventors: Ryan Wicker, Francisco Medina, Bart Chavez, Don Davis, Phillip Gallegos, Jeremy Palmer
Patent No. 8,252,223

Description:
"This patent is a 3D printing system capable of manufacturing fully functional electromechanical systems. The system efficiently builds single and multi-layered additively manufactured parts embedded with complex three-dimensional circuitry using direct-write. "

Abstract:
An integrated system and method of integrating fluid dispensing technologies (e.g., direct-write (DW)) with rapid prototyping (RP) technologies (e.g., stereolithography (SL)) without part registration comprising: an SL apparatus and a fluid dispensing apparatus further comprising a translation mechanism adapted to translate the fluid dispensing apparatus along the Z-, Y- and Z-axes. The fluid dispensing apparatus comprises: a pressurized fluid container; a valve mechanism adapted to control the flow of fluid from the pressurized fluid container; and a dispensing nozzle adapted to deposit the fluid in a desired location. To aid in calibration, the integrated system includes a laser sensor and a mechanical switch. The method further comprises building a second part layer on top of the fluid deposits and optionally accommodating multi-layered circuitry by incorporating a connector trace. Thus, the present invention is capable of efficiently building single and multi-material SL fabricated parts embedded with complex three-dimensional circuitry using DW.

Issue Date: 08/28/2012
Application Date: 12/23/2009
Post Date: 03/02/2018

UTEP Docket No: 2004-008
